Bandolero Wiring Harness Install | Go Motorsports Harness
Start switch.
Post 1= RED switched power
Post 2= RED or Blue Start
Ignition On (power)
Post 1= RED Power
Post 2 = RED switched Power
Kill switch. This switch is normally in the on position when running. So the switched would be turned opposite from the Ing power switch so they are all down when off. Notice the slots on the switches in the picture below.
Post 1= Yellow Kill
Post 2= Black Kill negative
